Sliding Mitre Saw
TE-SM 8 L Dual
Item no.:4300866EAN: 4006825659221
einhell-expert-sliding-mitre-saw-4300866-productimage-001
einhell-expert-sliding-mitre-saw-4300866-example_usage-001
einhell-expert-sliding-mitre-saw-4300866-detail_image-001
einhell-expert-sliding-mitre-saw-4300866-detail_image-002
einhell-expert-sliding-mitre-saw-4300866-detail_image-003
einhell-expert-sliding-mitre-saw-4300866-detail_image-004
einhell-expert-sliding-mitre-saw-4300866-detail_image-005
einhell-expert-sliding-mitre-saw-4300866-detail_image-006
einhell-expert-sliding-mitre-saw-4300866-productimage-001
einhell-expert-sliding-mitre-saw-4300866-example_usage-001
einhell-expert-sliding-mitre-saw-4300866-detail_image-001
einhell-expert-sliding-mitre-saw-4300866-detail_image-002
einhell-expert-sliding-mitre-saw-4300866-detail_image-003
einhell-expert-sliding-mitre-saw-4300866-detail_image-004
einhell-expert-sliding-mitre-saw-4300866-detail_image-005
einhell-expert-sliding-mitre-saw-4300866-detail_image-006
Sliding Mitre Saw

TE-SM 8 L Dual

Item no.: 4300866 EAN: 4006825659221
  • Special mounted traction function with perfect gliding qualities
  • Turntable with snap-in positions at the most common angles
  • Easy angle setting on the rotary table by quick adjustment
  • Clearly visible laser for precise cutting lines
  • Saw head can be tilted to the left and right for mitre cuts
  • Table extensions on both sides for longer workpieces
  • High-quality saw blade for perfect cutting results
  • Easy-to-reach spindle lock for simple saw blade changes
  • Clearly visible and readable angle scales
  • Incl. clamping device to fix the workpiece in place
  • Chip collector behind the saw blade for a clean workplace
  • Incl. suction connection (⌀ 36 mm)
See more information
Show less information
einhell-expert-sliding-mitre-saw-4300866-productimage-001
Article description

With the Einhell pull-cut mitre saw TE-SM 8 L Dual, the ambitious DIYer is ideally equipped for any kind of mitre cuts that occur in a project. With a powerful 1800W and an idle speed of 5,000 rpm, the robust Ø 216 mm carbide saw blade with 48 teeth works quickly and finely through the material. The stable saw has a smooth pulling function for wide workpieces. This enables a cutting width of max. 305 mm and a cutting depth of max. 65 mm. The precise angle adjustment on the aluminium turntable facilitates the desired oblique cuts. For the most common angles, snap-in positions are already provided in the turntable, which can be clearly read from the angle scale. The angle adjustment up to 47° to the left and right facilitates quick adjustment. The saw head can also be tilted up to 45° to the left and right with a quick adjustment and thus ensures a flexible and almost freely selectable miter cut. The clearly visible integrated cutting line laser and the depth stop make the work much easier. Supports for long workpieces are provided on the left and right respectively. To ensure that the workpieces can also be securely fixed, there is a practical clamping device. The easily accessible spindle lock makes it easier to change the saw blade and is quick to handle. For improved removal of sawdust, a chip collector is located behind the saw blade. In addition, a suitable wet/dry vacuum cleaner can be connected with the existing Ø 36 mm extractor, which keeps the workplace even cleaner.

Technical details

% power S625 %
Cutting depth 45° x 45°35 mm
Cutting depth 90° x 90°65 mm
Cutting width 45° x 45°215 mm
Cutting width 90° x 90°305 mm
Idle speed max.5000 min^-1
Max. swivel range (saw head)45 °
Max. swivel range (saw table)47 °
Min. swivel range (saw head)45 °
Min. swivel range (saw table)47 °
Number of saw blade 1 teeth48 pcs
Power S61800 W
Product weight13.25 Kg
Saw blade 1 diameter216 mm
Saw blade holder diameter30 mm
full_width_image
Quickly-adapted

Quickly adapted

The saw head, which can be tilted 45° to the left and right, can be easily adjusted to the respective cut by the quick adjustment.

Pull-cut--mitre-cut--sawing

Pull cut – mitre cut – sawing

The additional pull function increases the max. cutting width of the saw. This allows a cutting width of up to 305 mm.

Precise-cuts

Precise cuts

The integrated cutting line laser enables precise sawing. It allows the workpiece to be optimally aligned.

Get-to-work-safely

Get to work safely

The workpiece supports are adjustable to the left and right and the integrated clamping device fixes the workpiece.

Its-really-neat

It's really neat

With the integrated chip collector behind the saw blade, the sawdust is collected immediately after sawing and the workplace remains clean. In addition, a wet-dry vacuum cleaner can be connected to the Ø 36 mm suction connection.

Fine-fast-cut

Fine, fast cut

The Ø 216 mm tungsten carbide saw blade with 48 teeth enables an exact and fine cutting pattern with fast sawing progress. With the help of the easily accessible spindle lock, the saw blade can be changed quickly and easily.

Compact & handyPowerful & accurate at work

Equipped with a 1800-watt motor, the Einhell pull-cut mitre saw reliably cuts a wide variety of materials such as wood or wood-like materials. The robust aluminium rotary table has snap-in positions and an angle scale for top results.

Precise-angle-thanks-to-the-rotary-table

Precise angle thanks to the rotary table

The light and robust aluminium work table can be rotated by 47° to the left and right with the help of a quick adjustment. The exact cutting angle can be easily adjusted using the angle scale integrated into the turntable.

Perfect-mitre-cuts

Perfect mitre cuts

Thanks to the saw head, which can be tilted 45° to the left and right, the exact miter angle can be adjusted, which can be taken from an angle scale. The pull function allows a max. cutting width of 305 mm and a max. cutting depth of 65 mm.

Einhell customer service can be reached directly. We take care of your requests for product information, spare parts and repairs.We support you with all questions around your product - before, during and after the purchase.
